Name: Panasonic NCR26650A Non-standard battery (rechargeable) 26650 Flat top Li-ion 3.7 V 5 Ah 1 pc(s)
Brand: Panasonic
SKU: 3768032

Digital caliper measuring a green 26650 Li-ion battery, showing a diameter of 65.1 mm.

Datasheet (PDF)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Highlights & Details

Panasonic NCR26650A Li-Ion 3.7V/5.0Ah

Huge capacity of 5000 mAh for extra long running times
Proven premium quality from Panasonic
High cycle stability with up to 500 charge cycles
Stable voltage situation even under continuous load

Technical specifications

Charging procedure CC-CV (constant current - constant voltage)

Size: 26650

Product type: Non-standard battery (rechargeable)

Technology: Li-ion

Dim: (Ø x H) 26 mm x 65.3 mm

Voltage: 3.7 V

Capacity (mAh, Ah): 5 Ah

Special-purpose battery features: Flat top

Max. charge voltage: 4.2 V

Max. charging current: 3.4 A

Terminal voltage: 2.5 V

Discharge current (max.): 10 A

Continuous discharge: 5.5 A

Min. temperature: -20 °C

Max. temperature: 60 °C

Height: 65.3 mm

(Ø): 26 mm

Weight: 98 g

Content: 1 pc(s)

Type: NCR26650A

Rechargeable: Yes

Integrated surge protection: No

Documents & Downloads

Datasheet

Datasheet 3768032 Panasonic NCR26650A Non-standard battery (rechargeable) 26650 Flat top Li-ion 3.7 V 5 Ah 1 pc(s)

User & Safety Instructions

User & Safety Instructions 3768032 Panasonic NCR26650A Non-standard battery (rechargeable) 26650 Flat top Li-ion 3.7 V 5 Ah 1 pc(s)

Description

The Panasonic NCR26650A is the ideal energy source for applications where maximum endurance is required. With an impressive capacity of 5000 mAh, this industrial quality cell provides reliable and long-lasting power for high-Power torches, E-mobility or demanding DIY battery packs.
