Panasonic Thin film capacitor Radial lead 20 µF 1.100 V 10 % (L x W x H) 41.5 x 30.0 x 56.0 mm 1 pc(s)
Part number:
Item no:
Product type
Thin film capacitor
Type
Radial lead
Capacity (elec.)
20 µF
Nominal voltage
1.100 V
Dim
(L x W x H) 41.5 x 30.0 x 56.0 mm
Datasheet (PDF)
Highlights & Details
Panasonic MKP 20uF 1100V 41,5x30x56 RM37.5/20.3
Our service for you
Technical specifications
- ESD Packaging: No ESD
- Series EZPV
- Qualification: AEC-Q200
- Design_1: Radial
- Applications: DC filtering, DC link, solar inverters, wind power generation, industrial power supplies, Inverter circuit in devices (air conditioning systems, etc.), on-board chargers, AC/DC, DC/DC converters for motor vehicles
- Mounting type_1: THT
- Delivery form_1: Loose
- Connections_1: 4-pin
- Properties_1: Plastic foil capacitors
- Dielectric made of polypropylene (PPT) film, metalized
- Flame retardant (UL94 V-0, housing and sealing resin)
- High security (with safety function)
- Long life, high reliability
- Wire diameter 1.2 mm.
- Pitch_1:37.5 mm
- Capacity 20 µF
- Capacity_1: 20
- Unit of capacity: µF
- Capacity Tolerance 10%
- Dielectric: Metallized PP film
- Nominal voltage DC 1,100 V
- Product type
Thin film capacitor
- Type
Radial lead
- Dim
(L x W x H) 41.5 x 30.0 x 56.0 mm
- Capacity (elec.)
20 µF
- Nominal voltage
1.100 V
- Tolerance ±
10 %
- Height
56.0 mm
- Content
1 pc(s)
- Width
30.0 mm
- Length
41.5 mm
- RoHS-compliant
Yes
- Type
EZPV1B206MTB
- Operating temperature (max.)
105 °C
- Operating temperature (min.)
-40 °C
Documents & Downloads
Datasheet
Datasheet 3463506 Panasonic Thin film capacitor Radial lead 20 µF 1.100 V 10 % (L x W x H) 41.5 x 30.0 x 56.0 mm 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3463506 Panasonic Thin film capacitor Radial lead 20 µF 1.100 V 10 % (L x W x H) 41.5 x 30.0 x 56.0 mm 1 pc(s)
Description
Panasonic EZPV MPP film capacitor
