Patlite Light LED SKH-M1JB-B SKH-M1JB-B Blue Blue Emergency light 12 V DC, 24 V DC 88 dB
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Series: SK
- Conductor cross-section Starr: 0.13 mm² - 1.5 mm²
- WIRE CROSS-SECTION AWG: AWG 28 - AWG 14
- Dielectric strength: 4000 V/AC
- Mounting location: Indoor/outdoor
- Mounting method: 3 screws
- Wiring method: Cable
- Buzzer: With buzzer
- Mounting distance 70 mm
- Material (glove / body): PC
- Applicable standards: UL/cUL, CE, KC, EAC
- Product type
Light
- Operating voltage
12 V DC
24 V DC
- Max. current consumption
150 mA
- Colour
Blue
- (Ø)
100 mm
- Features
LED
IP23
IP65
- Dim
(Ø) 100 mm
- Factory colour
Blue
- Case colour
Blue
- Lighted picture
Rotating mirror
- Material
PC
- Signal type
Emergency light
- Type
SKH-M1JB-B
- Noise emission (max.)
88 dB
- Weight
0.000
- Calotte colour
Blue
- Max. temperature
+50 °C
- Min. temperature
-10 °C
- Acoustic signal
With buzzer
- Product type description
Lampe
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2248082 Patlite Light LED SKH-M1JB-B SKH-M1JB-B Blue Blue Emergency light 12 V DC, 24 V DC 88 dB
User & Safety Instructions
User & Safety Instructions 2248082 Patlite Light LED SKH-M1JB-B SKH-M1JB-B Blue Blue Emergency light 12 V DC, 24 V DC 88 dB
Description
Robust and reliable
The SK model is equipped with a brushless motor that produces less heat than a conventional motor and has a longer service life.
The steel ball bearing on the bottom of the reflector is designed in such a way that the wear is significantly reduced and that a quiet rotation of the reflector is ensured.
Better visibility
This newly developed dual reflector provides a brighter and evenly distributed light.
The light-emitting surface provides for maximum visibility and effective visual signals.
Through its comprehensive light rotation, the SK model can emit efficient visual signals in emergency situations.
Thanks to the long-life LED in the SK model, it is used as a permanently active warning light in 24-hour car parks where no parking attendant is present.
The SK model is mounted here on a driverless transport system. The rotating light is active when the system is in motion to prevent accidents when people approach it.
This text is machine translated.
The SK model is equipped with a brushless motor that produces less heat than a conventional motor and has a longer service life.
The steel ball bearing on the bottom of the reflector is designed in such a way that the wear is significantly reduced and that a quiet rotation of the reflector is ensured.
Better visibility
This newly developed dual reflector provides a brighter and evenly distributed light.
The light-emitting surface provides for maximum visibility and effective visual signals.
Through its comprehensive light rotation, the SK model can emit efficient visual signals in emergency situations.
Thanks to the long-life LED in the SK model, it is used as a permanently active warning light in 24-hour car parks where no parking attendant is present.
The SK model is mounted here on a driverless transport system. The rotating light is active when the system is in motion to prevent accidents when people approach it.
