PC Electric 253721-sr5 3-way connector Solid rubber 250 V Red IP54
EAN:
Part number:
Item no:
Datasheet (PDF)
Number
Total (€ 35.29 / piece)
€ 35.29
plus VAT.
Only 4 Piece(s) available
Highlights & Details
3-way coupling Taurus 2 solid rubber with red cover band nat 5p IP54
- 3-way coupling Taurus 2 full rubber with cover band
- Colour of housing/connection cover: Black/red
- Contact holder TPE
- This text is machine translated.
Technical specifications
- Number of poles: 3
- Product type
3-way connector
- Connector version
straight
- Nominal voltage
250 V
- Load (max.)
16 A
- Material
Solid rubber
- Factory colour
Red
IP54
- Type
Coupler CEE 7/3 (type F)
Documents & Downloads
Datasheet
Datasheet 3308223 PC Electric 253721-sr5 3-way connector Solid rubber 250 V Red IP54
User & Safety Instructions
User & Safety Instructions 3308223 PC Electric 253721-sr5 3-way connector Solid rubber 250 V Red IP54
Description
Features
- Ready wired to 5-pin terminal (PH1)
- Protective conductor system: Austrian/German system (type F - with protective conductor clamp)
- Contacts: Nickel-plated
- 250V~ / 16A / 2P+E
- Internal strain relief with kink protection sleeve
- For more difficult conditions
- Protection class: IP54
Scope of delivery
- 3-way coupling Taurus 2 nat DB 5p IP54
