A black electrical distribution box with multiple sockets: three blue sockets at the top, and at the bottom, one large grey socket and three red sockets, each with covers.

A black electrical distribution box with multiple sockets: three blue sockets at the top, and at the bottom, one large grey socket and three red sockets, each with covers.

PC Electric

Datasheet (PDF)

European union

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Technical specifications

1 x M40 screw connection above (cable diameter 22-32mm PG36) black
1 x blind screw joint M40 below
1 x CEE-socket 63A 5P 400V secured d. Feed-in fuse
1 x CEE-socket 32A 5P 400V secured ü. 1 x LS 32A 3P C
1 x CEE-socket 16A 5P 400V secured ü. 1 x LS 16A 3P C
3 x SK socket 16A 250V IP54 secured ü. 3 x LS 16A 1P C
1 x FI 63A/4/0.3A (TYPE A 63AT) via 63A output
1 x FI 63A/4/0.03A (TYPE A 63AT) via all 32A and 16A outputs
Circuit breaker switch and FI manufacturer Eaton EVE / VDE
Distributor on HVAC terminal (max. 5 x 25 qmm/5 x 16 qmmYF!) wired
Number of circuit breakers: 5
Feed/connection option: 2 lines (loop/loop-through)

Product type: CEE power distributor

No. of CEE connectors: 3

Type A: CEE socket (5-pin, 16 A)
CEE socket (5-pin, 32 A)
CEE socket (5-pin, 65 A)

Type B: PG socket

No. of PG sockets: 3

Nominal input voltage: 400 V

Nominal output voltage: 400 V

: IP54
IK08

Factory colour: Black

Dim: (W x H x D) 370 x 370 x 203 mm

Width: 370 mm

Height: 370 mm

Outputs (CEE power distributors): CEE connector (5-pin, 63 A)

Content: 1 pc(s)

Number of pins: 5

Depth: 203 mm

Documents & Downloads

Datasheet

European union

Datasheet 2389956 PC Electric CEE power distributor Bruck 92401633 400 V

Description

Wall distributor solid rubber series BRUCK BV 63/5 32/5 16/5 3xSSD M40oBVu EA IP54 TOP.

This text is machine translated.

Features

4-way wall mounting sealed from wiring room
Protection class II (standard)
Vulcanized brass nuts for lid mounting
Captive cover screws
Hinges between the bottom of the housing and the cover
Excellent impact resistance
High temperature and shape resistance
Very good electrical insulating properties
High resistance to weathering
UV and ozone resistant
Resistant to sweat and sparks
High mechanical strength
Resistant to aging and corrosion
Resistant to various oils, greases, acids etc.
Case made of solid rubber
Glow wire-proof 960 °C according to EN 60695-2-11
Non-flammable according to EN 60695-11-5
Mechanical resistance IK08 according to EN 50102
External rust-free metal parts
High-quality technical plastic parts.
