PCB adapter 09 14 002 2703 09140022703 HARTING 1 pc(s)
EAN:
Part number:
Item no:
Product type
PCB adapter
Case material
Polycarbonate
Type
09 14 002 2703
Manufacturer part #
09140022703
Connection
Socket
Datasheet (PDF)
Technical specifications
- Rated current 40 A
- Temperature limit: -40 ... +125 °C
- Material application: Polycarbonate (PC)
- Net weight: 22.26 g
- Rated voltage: 500 V
- Dimensioning surge voltage: 6 kV
- Pollution level 3
- Fire protection in rail vehicles: EN 45545-2 (2020-08)
- Gender: Jack
- Accessory type: PCB adapter
- Accessory description: In the HAN® 40 A Axial module
- Type
09 14 002 2703
- Product type
PCB adapter
- Manufacturer part #
09140022703
- Case material
Polycarbonate
- Connection
Socket
- Rated voltage
500 V
- Test current
40 A
- For insets/pin/socket
Buchse
- Content
1 pc(s)
- Max. temperature
125 °C
- Min. temperature
-40 °C
- Contamination level
3
500 V
FALSE
Bus
-40-125 °C
Other
6 kV
Other
Other
3
FALSE
Other
Thermoplastic
40 A
Thermoplastic
Documents & Downloads
Datasheet
Datasheet 3001727 PCB adapter 09 14 002 2703 09140022703 HARTING 1 pc(s)
Datasheet 3001727 PCB adapter 09 14 002 2703 09140022703 HARTING 1 pc(s)
User & Safety Instructions
User & Safety Instructions 3001727 PCB adapter 09 14 002 2703 09140022703 HARTING 1 pc(s)
Description
Socket, rated current 40 A, polycarbonate (PC)
