PCE Instruments PCE-917 Pressure gauge Pressure
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Pressure METER PCE-917
- Different units can be selected
- Display of under-, over- and differential pressure - Min-, Max- and Data-Hold function
- RS-232 interface
- For air and all non-aggressive gases and liquids
- 15 mm LCD display
- Stainless steel hose adapter
Technical specifications
- PSI Range 101.5 Resolution 0.05 / 0.1 mbar Range ±7000 Resolution 5 inH 2 O Range ±2800 Resolution 2 mH 2 O Range ±70.00 Resolution 0.05 inHg Range ±206.0 Resolution 0.1 mmHg Range ±5250 Resolution 5 Torr Range - Resolution - Pa / kPa range - Resolution - atm range ±6.905 Resolution 0.005 kg/cm 2 Range ±7.000 Resolution 0.005 Accuracy ±2% (full range) Repeatability ±1% Measurement sequence 0.8 s. Min- Max- Peak- Hold yes Interface RS-232 Supply 1 x 9 V block battery PP3 Plastic housing material Casing dimensions 180 x 72 x 32 mm Weight: 210g Caution: Exceeding the max. pressure range destroys the differential pressure gauge (the sensor)
- Product type
Pressure gauge
- Unit of measurement
Pressure
Manufacturer's standards (no certificate)
- Print resolution
5 mbar
- Dim
(L x W x H) 72 x 32 x 180 mm
- Weight
210 g
- Accuracy
2 %
- Width
32 mm
- Height
180 mm
- Length
72 mm
Documents & Downloads
Datasheet
Datasheet 2452282 PCE Instruments PCE-917 Pressure gauge Pressure
User & Safety Instructions
User & Safety Instructions 2452282 PCE Instruments PCE-917 Pressure gauge Pressure
Description
PCE-917 pressure gauge for liquid or/and air pressure, with RS-232 interface and optional software The digital differential pressure gauge is designed for use in difficult environments. This professional pressure gauge is particularly suitable for measuring hydraulic or pneumatic systems. The high-performance instrument with microprocessor control guarantees extreme accuracy and high reliability. With a short response time, as well as dust and splash-proof housing, the differential manometer is ideal for preventive maintenance. All models of the have a silicone insert that protects the differential pressure gauge or its sensors against the ingress of liquids. The measuring device is supplied factory calibrated, but can be laboratory calibrated and equipped with an ISO 9000 certificate. The calibration includes a test log, which is issued on the name of your company. In this way, you can record the differential manometer in your in-house test equipment pool according to ISO.
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1 x PPCE-917 pressure gauge
- 1 x battery
- 2 x special stainless steel hose adapter
- 1 x 1m hose
- 1 x carrying case
- 1x user manual
