PCE Instruments PCE-LM 4 PCE-LM 4 Lux meter 0 - 999.9 lx
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
PROFESSIONAL CALIBRATED TO EQUIPMENT. PCE-LM 4
- Measurement range up to 200 klx or 20 KFC
- Resolution from 0.1 lx
- Accuracy ±3% + 8 digits
- MIN / MAX / HOLD
- Measurement of the ambient temperature
- Memory for 12 measurements
Technical specifications
- Lighting
- Measuring range 0 lx ... 999.9 lx
- Resolution 0.1 lx
- Accuracy ± (3 % from MW. ±8 digits)
- Lighting
- Measuring range 1000 lx ... 200 lx
- Resolution 1 lx
- Accuracy ± (3 % from MW. ±8 digits) <10,000 lx, ± (4 % of MW. ±10 digits ) >=10,000 lx
- Lighting
- Measuring range 0 fc ... 99.9 fc
- Resolution 0.01 fc
- Accuracy ± (3 % from MW. ±8 digits) <1000 fc, ± (4% of MW. ±10 digits ) >=1000 fc
- Lighting
- Measuring range 100 fc ... 20 kfc
- Resolution 0.1 fc
- Accuracy ± (3 % from MW. ±8 digits) <1000 fc, ± (4% of MW. ±10 digits ) >=1000 fc
- Temperature
- Measurement range -20 °C ... +70 °C
- Resolution 0.1 °C
- Accuracy +/1.5 °C
- Temperature
- Measuring range -4 °F ... +158 °F
- Resolution 0.1 °F
- Accuracy: ±2.7 °F
- General Technical Data
- MEASUREMENT FUNCTIONS MIN, MAX, HOLD
- Units lx, fc, °C, °F
- Display type LCD with lighting
- Display update rate 2 x per second
- Storage medium Internal memory
- Memory capacity: 12 values
- Operating time 60 h
- Automatically switches off approx. 15 min.
- Menu language English
- Protection class (device) IP20
- Weight 90 g
- Depth 31 mm
- 80 mm diameter
- Operating conditions -20 ... 60 °C , 0 ... 90 % r.F.
- Storage conditions -20 ... 60 °C , 0 ... 75 % r.F.
- Product type
Lux meter
- Reading type
Light intensity
Manufacturer's standards (no certificate)
- Dim
(L x W x H) 80 x 80 x 80 mm
- Display
LCD
- Weight
90 g
- Features
Data logger
- Illuminance reading range
0 - 999.9 lx
- Illuminance reading range (max.)
999.9 lx
- Illuminance reading range (min.)
0 lx
- Illuminance reading accuracy
3 %
- Width
80 mm
- Height
80 mm
- Length
80 mm
Documents & Downloads
Datasheet
Datasheet 3192924 PCE Instruments PCE-LM 4 PCE-LM 4 Lux meter 0 - 999.9 lx
User & Safety Instructions
User & Safety Instructions 3192924 PCE Instruments PCE-LM 4 PCE-LM 4 Lux meter 0 - 999.9 lx
Description
With its compact size and easy handling, this Luxmeter is the ideal measuring instrument for all those who would like to perform quick light measurements. After removing the lid the Luxmeter will give reliable results in seconds. With a large measurement range of up to 200 Klx or 20 KFC, the Luxmeter can be used for a wide range of applications in different lighting environments.
With its min/max hold value display, the Luxmeter ensures that the most important values are not overlooked, while the temperature display gives additional information about the measurement environment. The Luxmeter has an easy to read LCD screen. The internal memory can store and retrieve up to 12 measured values.
The automatic cut-off function prevents uncontrolled discharge of the batteries. With the lid open, the Luxmeter turns off automatically after 15 minutes and with the lid closed after one minute of inactivity. With standard AAA batteries an operating time of up to 60 hours can be achieved.
This text is machine translated.
With its min/max hold value display, the Luxmeter ensures that the most important values are not overlooked, while the temperature display gives additional information about the measurement environment. The Luxmeter has an easy to read LCD screen. The internal memory can store and retrieve up to 12 measured values.
The automatic cut-off function prevents uncontrolled discharge of the batteries. With the lid open, the Luxmeter turns off automatically after 15 minutes and with the lid closed after one minute of inactivity. With standard AAA batteries an operating time of up to 60 hours can be achieved.
This text is machine translated.
Features
- Internal memory up to 12 values
- Min-Max-HOLD display
Scope of delivery
- 1 x Luxmeter PCE-LM 4
- 1 x cases
- 2 x 1.5 V AAA battery
- 1x user manual
