PCE Instruments PCE-PH20M pH meter Temperature, pH
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Food pH meter PCE-PH20M for meat
- Waterproof (IP 67)Special external measuring electrode on cableHigh accuracyAuto power-off for battery protectionSupplied with calibration solutionsData hold functionEasy to read digital displayEasy to use
Technical specifications
- Measurement range 0.00...14.00 pH Resolution 0.01 pH Accuracy ±0.07 pH (in the range 5 ... 9 pH) ±0.1 pH (in the range 4 ... 4.9 and 9.1 ... 10 pH) ±0.2 pH (in the range 1 ... 3.9 and 10 ... 13 pH) Calibration automatically, at pH 4, 7, or 10 using calibration solutions Electrode food pH electrode CPC-OSH-12-01 BNC plug Power supply 4 x 1.5 V AAA batteries Ambient conditions 0 ... +60 °C /< 80 % RH Dimensions 180 x 40 mm Weight 220 g.
- Product type
pH meter
- Reading type
Temperature
pH
- Display
LCD
Manufacturer's standards (no certificate)
- Dim
(L x W x H) 40 x 25 x 180 mm
- Weight
220 g
- Temperature reading range
0 up to 60 °C
- Temperature reading range (max.)
60 °C
- Temperature reading range (min.)
0 °C
- pH reading range
0 - 14 pH
- pH reading range (max.)
14 pH
- pH reading range (min.)
0 pH
- Width
25 mm
- Height
180 mm
- Length
40 mm
- Interfaces
BNC plug
Documents & Downloads
Datasheet
Datasheet 2452578 PCE Instruments PCE-PH20M pH meter Temperature, pH
User & Safety Instructions
User & Safety Instructions 2452578 PCE Instruments PCE-PH20M pH meter Temperature, pH
Description
Food pH meter PCE-PH20M easy to use pH meter for determining pH value / external pH electrode / recalibrable / waterproof (IP 67) the PH meter was developed to determine the pH value directly in aqueous media. The PPCE-PH20 waterproof pH tester is designed to quickly and accurately measure pH. The practical display makes it easy to read the pH value at the pH meter. The waterproof and robust housing (IP 67) means that the pH-value tester can also be used under difficult conditions. Recalibration always guarantees optimum accuracy and is very easy to carry out using the optionally available calibration kits (automatic calibration function without calibration screws - only to be carried out via the keyboard).
This text is machine translated.
This text is machine translated.
Scope of delivery
- 1 x food pH meter PCE-PH20M 1 x pH electrode CPC-OSH-12-01 (for food) 4 x battery 1 x Calibration Kit with Solutions pH4 + 7 (75 ml vials each) 1 x operating instructions
