PCE Instruments PCE-SD 1500U SST Platform scales PCE-SD 1500U SST Weight range 1500 kg Readability 500 g via PSU, mains-
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Stainless steel floor scales PCE-SD 1500U SST
- Calibratable (supplied with Calibration) Made entirely of IP68 stainless steel IP65 Piece-counting function Sum function Max. / Min. Display Percentage weighing Recipe weighing Statistics function Animal weighing function Gross/Net display Tare storage LIMIT VALUE WEIGHING MIN / MAX / OK 3 optional potential-free contactsAnalogue outputs optional (4-20 mA / 0-10V)
Technical specifications
- MODEL PCE-SD 1500U SST Measurement range 1,500 kg Readability 0.5 kg Calibration value 0.5 kg Minimum load* 10 kg * The minimum load, is the load from which the calibration authority checks the accuracy. The stainless steel U-shape pallet scales also show smaller weights, but these must not be used in the approved traffic. Calibration class M III (delivered calibrated) Piece counting function by reference piece counting Tare function via the full measurement range Interface optional RS-232 / LAN / USB (please observe the IP protection class) Display LED with 20 mm digit height Power supply ~230V, 50Hz, 8VA Protection class cells IP68 / display IP65 Operating temperature - 10 °C ... 40 °C Weight approx. 70 kg
- Weight range
1500 kg
- Product type
Platform scales
- Readability
500 g
- Display
Digital
- Power supply (LOV)
via PSU
mains-powered
Manufacturer's standards (no certificate)
- Factory colour
Silver/stainless steel
- Dim
(L x W x H) 190 x 140 x 65 mm
- Weight
70000 g
- Weight resolution
0.5 kg
- Calibratable
Yes
- Weighing plate
Stainless steel
- Width
140 mm
- Height
65 mm
- Length
190 mm
- Type
PCE-SD 1500U SST
- Features
Calibrated
Counting
- Top plate (width)
1260 mm
- Top plate (length)
960 mm
Documents & Downloads
Datasheet
Datasheet 2813634 PCE Instruments PCE-SD 1500U SST Platform scales PCE-SD 1500U SST Weight range 1500 kg Readability 500 g via PSU, mains-
User & Safety Instructions
User & Safety Instructions 2813634 PCE Instruments PCE-SD 1500U SST Platform scales PCE-SD 1500U SST Weight range 1500 kg Readability 500 g via PSU, mains-
Description
The stainless steel U-shaped curved scale is a calibrated scale. The dimensions of the stainless steel U-shape floor scales are designed exactly for an EU palette. The U-shape of the stainless steel floor scales allows for easy and fast loading by moving the pallet truck between the two beams and placing the pallet on them. The four cells of the stainless steel U-shape floor scales are IP68 protected and hide on the edges of the frame. The weighing frame is made of solid corrosion and acid-resistant stainless steel. The display of the stainless steel U-shaped weighing scale is IP65 protected and can be mounted on the table or on the wall. It is possible to use the stainless steel U-shape floor scales with optional interfaces, such as RS-232, USB, LAN, 4-20 mA etc. to be provided but this would have a significant effect on the protection class. To carry the stainless steel U-shape floor scales are mounted on the spar transport rollers. Functions of the stainless steel U-shape floor scales include autotara, batch counting function, tare storage, gross/net weighing, percentage weighing, limit weighing etc.
This text is machine translated.
This text is machine translated.
Features
- Calibrated stainless steel U-shape floor scalesincl. super smash bros. Transport rollersIP68 - IP65Piece-counting functionSum functionAnalog outputs 4 ... 20 mA - 0 ... 10 V optional
Scope of delivery
- 1 x stainless steel U-shape floor scales included Calibration and operating instructions.
