PCE Instruments PCE-SPM 1 PV tester 0 - 2000 W/m²

Test device with integrated sensor, determines the energy yield on solar systems / also serves to find optimal solar locations for new systems The measuring device for solar energy is the optimal hand - test device for solar engineers, architects and hobby solar engineers. With this measuring device you can determine the solar power. Other nominal data (current, voltage, ...) can be determined in parallel with a separate test device ( data logger multimeter ). This makes it possible to make a statement about the composition and design of a photovoltaic system. The light intensity is measured by a monocrystalline silicon solar cell. The processor integrated in the solar energy meter provides for an automatic correction to maintain the basic accuracy after calibration of each device in the solar simulator. The most important parameter P tot (in W/m²) can be read directly on the display. The data contained in the internal memory (32,000 measured values) can be transferred to the serial interface of a PC with the help of the software. This solar energy meter is also designed for outdoor use and has a weather-resistant plastic housing. Its compact dimensions allow a comfortable one-handed operation.
