Buy PCE Instruments PCE-WB 20SD Hygrometer

Portable heat stress meter with black globe sensor, digital display, and control buttons<br>

Handheld sound level meter with a large black spherical microphone and LCD display, used for measuring noise levels.

Digital thermometer-hygrometer display showing 31.1°C and 19.9% RH on a handheld device.

Handheld sound level meter with windscreen and carrying case, shown with USB card reader and SD card adapter.

1/4

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Technical specifications

Technical specifications Units of measurement WBGT Black Globe Temperature (TG) Air temperature (TA) Wet-bulb temperature (WB) Dew point temperature WBGT Reading range Inside: 0 ... +59 °C Outside: 0 ... +56 °C Accuracy inside ± 1 °C (+15 ... +59 °C) ± 1.5 °C (other temperature ranges) Accuracy outdoors ± 1.5 °C (+15 ... +56 °C) ± 2 °C (other temperature ranges) Air temperature (TA) Measurement range 0 ... +50 °C Resolution 0.1 °C Accuracy ± 0.8 °C Black Globe temperature Measurement range 0 ... +80 °C Resolution 0.1 °C Accuracy: ±0.6 °C Humidity Measuring range 5 ... 95% RH Resolution 0.1 % RH Accuracy > 70% RH: ± (3% reading + 1% RH) < 70% RH: ± 3% RH Dew point temperature Measuring range -25.3 ... +48.9 °C Resolution 0.1 °C Wet bulb temperature Measuring range -21.6 ... +50 °C Resolution 0.1 °C +B611General data WBGT formula Inside/outside and no sun: WBGT = (0.7 x WB) + (0.3 x TG) Outside and sun: WBGT = (0.7 x WB) + (0.2 x TG) + (0.1 x TA) Data storage intervals Automatic: All 1 ... 3,600 sec. Manual: With every push of a button Memory card SD memory card 1 ... 16 GB Interface RS 232 / USB Display LCD with background lighting (52 x 38 mm) Operating temperature 0 ... +50 °C Ambient humidity< 85 % RH Power supply 6 x 1.5 V AA batteries or 9 V adapter Power consumption DC 14 mA in normal operation DC 37 mA in data storage and switched off display lighting Weight 489 g. Dimensions Device: 177 x 68 x 445 mm Ball: Ø 75 mm

Product type: Hygrometer

: Manufacturer's standards (no certificate)

Documents & Downloads

Datasheet

Datasheet 2452779 PCE Instruments PCE-WB 20SD Hygrometer

User & Safety Instructions

User & Safety Instructions 2452779 PCE Instruments PCE-WB 20SD Hygrometer

Description

PCE-WB 20SD industrial safety meter with data logger function for an objective assessment of working conditions in extreme weather conditions The PCE-WB 20SD industrial safety meter measures WBGT values in indoor and outdoor areas, the black globe temperature, humidity, air temperature, wet ball temperature and the dew point temperature. This makes the OSH meter the ideal instrument for objectively determining working conditions in extreme weather conditions, as well as appropriate levels for physical activities. The integrated data logger function enables the storage of up to 99 measured values in intervals of 1 - 3,600 seconds or by pressing a button on the safety measuring device. The recorded data can be read from the SD card or via USB/RS 232 on a PC and further analyzed in Excel.

This text is machine translated.
