PCE Instruments Sound level meter Calibrated to (ISO standards) Data logger PCE-MSL 1-ICA 35 dB (min.) 31.5 Hz - 8 kHz
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
PCE instruments sound level meter PCE-MSL 1-ICA
- Extreme value measurement
- High accuracy
- Quick volume measurements
- Backlit color LCD
- Simultaneous temperature measurement
- HOLD function
- Big frequency range
- A-frequency evaluation
- Robust ABS-plastic casing
- 1/2 inch electret condenser microphone
- Slow / fast time evaluation
- Alarm when the frequency is exceeded
- Resolution 0.1dB
- Display update every 300 ms
- Incl. ISO calibration certificate
Technical specifications
- Sound level
- Measuring range 35 ... 135 dB
- Resolution 0.1 dB
- Accuracy ±2 dB
- Temperature
- Measuring range -20 ... +70 °C
- Resolution 0.1 °C
- Accuracy +/1.5 °C
- General Technical Data
- MEASUREMENT FUNCTIONS HOLD, MAX., MIN.
- Time rating slow (1 s), fast (125 ms)
- Frequency weighting A
- Frequency 31.5 ... 8000 Hz
- Display type LCD with lighting
- Measurement rate 3.33 Hz
- Microphone type Electret capacitor
- Operating time 60 h
- Automatically switches off approx. 15 min.
- Dimensions Diameter of microphone 1/2 inch
- Menu language English (US), English (GB)
- Protection class (device) IP20
- Battery/Battery 3 x 1.5 V AAA Battery , Zinc manganese dioxide
- Capacity 1200 mAh
- Operating conditions -20 ... 60 °C , 10 ... 90 % r.F.
- Storage conditions -20 ... 60 °C , 10 ... 75 % r.F.
- Dimensions ( L x W x H ) 144 x 56 x 31 mm
- Weight 75 g
- Product type
Sound level meter
- Reading type
SPL
- SPL resolution
0.1 dB
ISO standards
- Dim
(L x W x H) 190 x 56 x 47 mm
- Display
LCD
- Max. frequency
8 kHz
- Min. frequency
31.5 Hz
- Frequency range
31.5 Hz - 8 kHz
- dB (A) accuracy
2 dB
- Weight
75 g
- Calibration service
Incl. ISO calibration certificate
- dB SPL (A) reading range
35 dB (min.)
- dB (A) SPL reading range (min.)
35 dB
- Width
56 mm
- Height
47 mm
- Length
190 mm
- Features
Data logger
- Plastic free packaging
Plastic-free packaging
Documents & Downloads
Datasheet
Datasheet 3812636 PCE Instruments Sound level meter Calibrated to (ISO standards) Data logger PCE-MSL 1-ICA 35 dB (min.) 31.5 Hz - 8 kHz
User & Safety Instructions
User & Safety Instructions 3812636 PCE Instruments Sound level meter Calibrated to (ISO standards) Data logger PCE-MSL 1-ICA 35 dB (min.) 31.5 Hz - 8 kHz
Description
The sound level meter is a simple sound level meter. The sound level meter is used for quickly determining the ambient volume. Apart from measuring the volume, the sound level meter can also determine the ambient temperature. The measurement of the noise background is important in almost every situation.
For this purpose, it is helpful to use a simple sound level meter that gives the user an initial idea about the possible noise exposure. The LC-Display gives clear results via the sound level meter made measurements. A background lighting is also integrated in the display. This sound level meter is especially suitable for measurements that need to be unstationary.
This text is machine translated.
For this purpose, it is helpful to use a simple sound level meter that gives the user an initial idea about the possible noise exposure. The LC-Display gives clear results via the sound level meter made measurements. A background lighting is also integrated in the display. This sound level meter is especially suitable for measurements that need to be unstationary.
This text is machine translated.
Scope of delivery
- 1 x sound level meter PCE-MSL 1-ICA
- 1 x wind noise suppressor
- 3 x 1.5 V AAA battery
- 1x user manual
- 1 x ISO calibration certificate
