PCE Instruments Sound level meter Calibrated to (ISO standards) Data logger PCE-SLD 10-ICA 30 - 80 dB 31.5 Hz - 8000 Hz

The sound level data logger is used for permanent monitoring of the sound level. In addition to the storage of the measured values, the sound level data logger is able to display the measured values on a display and as 4 ... 20 mA analog value to be output. The sound level data logger has a wide measuring range of 30 ... 130 dB The frequency is evaluated in A or C. Depending on the selected measuring mode, the sound level data logger can measure the sound level in fast or slow mode.

The measured values are saved by the sound level data logger as an Excel file on a memory card. This has the advantage that, after measuring, the SD memory card can simply be removed from the sound level data logger and data can be evaluated without the need for an additional software. The sound level-data logger is operated by 6 x 1.5 V AAA batteries. For long-term use, an external power adapter is enclosed with the sound level data logger.

The sound level data logger is used wherever the noise level needs to be continuously monitored and a control system needs to perform further actions. For example, in a production hall, this can be the visualization of the sound level on a large display. Also, when the sound level is exceeded, windows and doors can be closed in connection with switchgear.

This text is machine translated.
