Pepperl+Fuchs KCD2-SOT-1.LB 214246 Amplifier 1 pc(s)
EAN:
Part number:
Item no:
Product type
Amplifier
Type
KCD2-SOT-1.LB
Dim
(L x W x H) 114 x 12.5 x 119 mm
Connection
Power Rail
Clamp
Operating voltage
19 - 30 V DC
Datasheet (PDF)
Technical specifications
- Safety integrity level (SIL): SIL 2
- Connection side: Field side
- Open circuit voltage/short circuit current: Approx. 10 V DC / approx. 8 mA
- Display elements: LEDs
- Controls: Dip switch
- Configuration: Via DIP switch
- Labeling: Space for labeling on the front side
- Weighs about 100 g
- Mounting: On 35 mm DIN rail according to EN 60715;2001
- Signal type: Binary input
- Type
KCD2-SOT-1.LB
- Product type
Amplifier
- Dim
(L x W x H) 114 x 12.5 x 119 mm
- Connection
Power Rail
Clamp
- Operating voltage
19 - 30 V DC
- Max. operating voltage
30 V DC
- Min. operating voltage
19 V DC
- Input signal (voltage)
ca. 10 V DC
- Input signal (current)
ca. 8 mA
- Content
1 pc(s)
- Configuration
DIP switch
- Width
12.5 mm
- Height
119 mm
- Length
114 mm
- Max. ambient temperature
+60 °C
- Min. ambient temperature
-20 °C
- Supply voltage (num.)
24 V DC
- Operating voltage U(B)
19...30 V DC
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2230511 Pepperl+Fuchs KCD2-SOT-1.LB 214246 Amplifier 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2230511 Pepperl+Fuchs KCD2-SOT-1.LB 214246 Amplifier 1 pc(s)
