Pepperl+Fuchs One-way light barrier ML29-P/25/102/115 129309 Light-ON 1 pc(s)
EAN:
Part number:
Item no:
Product type
One-way light barrier
Functions
Light-ON
Max. operating voltage
30 V DC
Connector
Cable
Type
ML29-P/25/102/115
Datasheet (PDF)
Technical specifications
- Product type
One-way light barrier
- Type
ML29-P/25/102/115
- Functions
Light-ON
- Min. operating voltage
11 V DC
- Max. operating voltage
30 V DC
- Operating voltage
11 - 30 V DC
- Response time
5 ms
- Outputs
NPN
- Switching frequency
100 Hz
- Connector
Cable
- Cable length
6 m
- Enclosure material
PMMA
- Transmitter type
IRED
- Light emission
lateral
8.5 m
- Min. temperature
-20 °C
- Max. temperature
60 °C
- Content
1 pc(s)
- Wireless charging
No
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2629199 Pepperl+Fuchs One-way light barrier ML29-P/25/102/115 129309 Light-ON 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2629199 Pepperl+Fuchs One-way light barrier ML29-P/25/102/115 129309 Light-ON 1 pc(s)
Description
Hints
For more information on this 129309, please refer to its datasheet under 'downloadable documents'
