Pepperl+Fuchs Pushbutton ML100-8-W-200-RT/95/103 235961 Clear object detection 1 pc(s)
EAN:
Part number:
Item no:
Product type
Pushbutton
Functions
Clear object detection
Max. operating voltage
30 V DC
Connector
M8 x 1 plug (4-pin)
Type
ML100-8-W-200-RT/95/103
Datasheet (PDF)
Technical specifications
- Light Spot Diameter: approx. 170 mm at a distance of 200 mm
- Product type
Pushbutton
- Type
ML100-8-W-200-RT/95/103
- Functions
Clear object detection
- Operating voltage
30 V DC
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Outputs
PNP
- Connector
M8 x 1 plug (4-pin)
- Enclosure material
PC
- Transmitter type
LED red
200 mm
IP67
- (Ø)
170 mm
- Dim
(Ø) 170 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 2130312 Pepperl+Fuchs Pushbutton ML100-8-W-200-RT/95/103 235961 Clear object detection 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2130312 Pepperl+Fuchs Pushbutton ML100-8-W-200-RT/95/103 235961 Clear object detection 1 pc(s)
Conformity certificate
Conformity certificate 2130312 Pepperl+Fuchs Pushbutton ML100-8-W-200-RT/95/103 235961 Clear object detection 1 pc(s)
Description
Reflective light sensors with a rectangular light spot for transparent detection, sensing range 200 mm, red light, light/dark switching, sensitivity adjuster, DC-version, PNP output, M8 connector
This text is machine translated.
This text is machine translated.
Hints
For more information on this 235961, please refer to its datasheet under 'downloadable documents'
