Pepperl+Fuchs Pushbutton RL28-8-H-1500-LAS/105/110 196304 Switch (light-ON/dark-ON) 1 pc(s)
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Pushbutton
Functions
Switch (light-ON/dark-ON)
Max. operating voltage
30 V DC
Connector
M12 plug (5-pin)
Datasheet (PDF)
Technical specifications
- Switching voltage max. 30 V/DC, type: bright/dark switch, switchable, switching current 100 mA
- Packaging type
Piece
- Product type
Pushbutton
- Type
RL28-8-H-1500-LAS/105/110
- Functions
Switch (light-ON/dark-ON)
- Operating voltage
30 V DC
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Response time
3.5 ms
- Switching frequency
140 Hz
- Connector
M12 plug (5-pin)
- Enclosure material
Plastic
Acrylonitrile butadiene styrene
- Transmitter type
Laser diode
- Laser class
1
- Wavelength
650 nm
- Features
Incl. background suppression
IP67
- Min. temperature
-10 °C
- Max. temperature
+50 °C
- Width
25.8 mm
- Height
88 mm
- Depth
54.3 mm
- Dim
(W x H x D) 25.8 x 88 x 54.3 mm
- Content
1 pc(s)
Documents & Downloads
Datasheet
Datasheet 2130684 Pepperl+Fuchs Pushbutton RL28-8-H-1500-LAS/105/110 196304 Switch (light-ON/dark-ON) 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2130684 Pepperl+Fuchs Pushbutton RL28-8-H-1500-LAS/105/110 196304 Switch (light-ON/dark-ON) 1 pc(s)
Conformity certificate
Conformity certificate 2130684 Pepperl+Fuchs Pushbutton RL28-8-H-1500-LAS/105/110 196304 Switch (light-ON/dark-ON) 1 pc(s)
Description
Reflective light sensors with background suppression
This text is machine translated.
This text is machine translated.
Hints
For more information on this 196304, please refer to its datasheet under 'downloadable documents'
