Buy Pepperl+Fuchs Pushbutton RL28-8-H-700-IR/47/105 419614 Light-ON, Background suppression, Switch (light-ON/dark-ON), Dark

A rectangular electronic sensor with a green-black housing and lens on the front, suitable for distance measurement.

Image similar

Product type

Pushbutton

Functions

Light-ON

Background suppression

Switch (light-ON/dark-ON)

Dark-ON

Max. operating voltage

30 V DC

Connector

M12 plug (5-pin)

Type

RL28-8-H-700-IR/47/105

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad Electronic Terms & Conditions

Report legal concerns

Technical specifications

Light Spot Diameter: approx. 24 mm at a distance of 700 mm, switching voltage max. 30 V/DC, type: bright/dark switch, switchable, switching current 200 mA

Product type: Pushbutton

Type: RL28-8-H-700-IR/47/105

Functions: Light-ON
Background suppression
Switch (light-ON/dark-ON)
Dark-ON

Operating voltage: 30 V DC

Min. operating voltage: 10 V DC

Max. operating voltage: 30 V DC

Operating voltage: 10 - 30 V DC

Response time: 2 ms

Switching frequency: 250 Hz

Connector: M12 plug (5-pin)

Enclosure material: Plastic
Acrylonitrile butadiene styrene

Transmitter type: LED IR

Features: Incl. background suppression

: IP67

Min. temperature: -40 °C

Max. temperature: +60 °C

Width: 25.8 mm

Height: 88 mm

Depth: 54.3 mm

(Ø): 24 mm

Dim: (Ø x H) 24 mm x 88 mm

Content: 1 pc(s)
