Name: Pepperl+Fuchs Pushbutton RL31-8-2500-IR/115/136 207545 Light-ON 1 pc(s)
Brand: Pepperl+Fuchs
SKU: 2130532

A rectangular sensor from Visolux with a black housing and green front plate, showing circuit diagram and CE marking.

Image similar

Product type

Pushbutton

Functions

Light-ON

Max. operating voltage

30 V DC

Connector

Cable, 4-core

Type

RL31-8-2500-IR/115/136

Datasheet (PDF)

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Light Spot Diameter: approx. 50 mm at a distance of 2.5 m, type: brightness switch

Product type: Pushbutton

Type: RL31-8-2500-IR/115/136

Functions: Light-ON

Operating voltage: 30 V DC

Min. operating voltage: 10 V DC

Max. operating voltage: 30 V DC

Operating voltage: 10 - 30 V DC

Connector: Cable, 4-core

Cable length: 2.00 m

Enclosure material: Polycarbonate (PC)

Transmitter type: LED IR

: 2500 mm

: IP67

Width: 18 mm

Height: 62 mm

Depth: 35 mm

(Ø): 50 mm

Dim: (Ø x H) 50 mm x 62 mm

Content: 1 pc(s)

Documents & Downloads

Datasheet

Datasheet 2130532 Pepperl+Fuchs Pushbutton RL31-8-2500-IR/115/136 207545 Light-ON 1 pc(s)

User & Safety Instructions

User & Safety Instructions 2130532 Pepperl+Fuchs Pushbutton RL31-8-2500-IR/115/136 207545 Light-ON 1 pc(s)

Conformity certificate

Conformity certificate 2130532 Pepperl+Fuchs Pushbutton RL31-8-2500-IR/115/136 207545 Light-ON 1 pc(s)

Description

Reflective light sensor, energetic, plastic case, sensing range 2500 mm adjustable, infrared light, light switch, 2 push-pull outputs, fixed cable

This text is machine translated.

Hints

For more information on this 207545, please refer to its datasheet under 'downloadable documents'

Description

Reflective light sensor, energetic, plastic case, sensing range 2500 mm adjustable, infrared light, light switch, 2 push-pull outputs, fixed cable
