Pepperl+Fuchs Sensor Inductive NBB4-F1-A2 5M 910389 shielded PNP (Ø) 5.2 mm
EAN:
Part number:
Item no:
Product type
Sensor
Max. operating voltage
30 V
Contact type
Antivalent
Switching distance (max.)
4 mm
Outputs
PNP
Datasheet (PDF)
Technical specifications
- Product type
Sensor
- Type
NBB4-F1-A2 5M
- Min. operating voltage
10 V
- Max. operating voltage
30 V
- Operating voltage
10 - 30 V
- Contact type
Antivalent
- Switching distance (max.)
4 mm
- Outputs
PNP
- Enclosure material
Polyamide
- Model
Inductive
- Installation type
shielded
- Connector
Cable
- Cable length
5 m
- Features
LED indicator
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP67
- (Ø)
5.2 mm
- Dim
(Ø) 5.2 mm
- Content
1 pc(s)
- Wireless charging
No
- Switching frequency
1400 Hz
- UKCA
not relevant
