Image similar
Pepperl+Fuchs Sensor Inductive NBB4-F1-E3-6M 194908 shielded PNP
EAN:
Part number:
Item no:
Product type
Sensor
Max. operating voltage
30 V
Contact type
1 breaker
Switching distance (max.)
4 mm
Outputs
PNP
Datasheet (PDF)
Technical specifications
- Product type
Sensor
- Type
NBB4-F1-E3-6M
- Min. operating voltage
10 V
- Max. operating voltage
30 V
- Operating voltage
10 - 30 V
- Contact type
1 breaker
- Switching distance (max.)
4 mm
- Outputs
PNP
- Enclosure material
Polyamide
- Model
Inductive
- Installation type
shielded
- Connector
Cable
- Cable length
6 m
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP67
- Content
1 pc(s)
- Wireless charging
No
- Switching frequency
1400 Hz
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2627834 Pepperl+Fuchs Sensor Inductive NBB4-F1-E3-6M 194908 shielded PNP
User & Safety Instructions
User & Safety Instructions 2627834 Pepperl+Fuchs Sensor Inductive NBB4-F1-E3-6M 194908 shielded PNP
Description
Switching distance: 4 mm, installation: Flush, switching function: NC contact (NC), output type: PNP, operating voltage: 10 ... 30 V, operating current: 0 ... 250 mA
This text is machine translated.
This text is machine translated.
Features
- General dataSwitching function: NC contact (NC)Output type: PNPSwitching distance: 4 mmInstallation: FlushOutput polarity: DCSafe switching distance: 0 ... 3.24 mmReduction factor forAl: 0.4Reduction factor rCu: 0.45Reduction factor rV2A (1.4301) : 0.8Reduction factor rMS: 0.55Output type: 3-wireCharacteristicsOperating voltage 10 ... 30 VSwitching frequency: 0 ... 1400 HzHysteresis: type. 5%Reverse polarity protection: Reverse polarity protectedShort-circuit protection: IsochronousVoltage drop: ≤ 2.5 VRated insulation voltage 60 V.Operating current: 0 ... 250 mAResidual current: 0 ... 0.01 mA type. 0.1 µA at 25 °C.No-load current ≤ 15 mASwitching status indicator: LED, yellowFunctional safety characteristicsMTTFd: 1640 a.Service life (TM): 20 a.Diagnostic coverage level (DC): 0%Compliance with standards and directivesCompliance Standards EN 60947-5-2:2007 | IEC 60947-5-2:2007Approvals and certificatesProtection class: II Rated insulation voltage 60 V. Rated surge voltage resistance 800 V.UL approval: CULus Listed, General PurposeCSA approved: CCSAus Listed, General PurposeCCC approval: Products with a maximum operating voltage of ≤36 V are not subject to approval and therefore do not have a CCC marking.Ambient conditionsAmbient temperature: -25 ... 70 °C (-13 ... 158 °F)Mechanical data:Connection type: Cable PVC, 6 mCore cross-section 0.5 mm2Housing material: PAFront face: PAProtection class IP67Tightening torque mounting screws: Thread M3 max. 1.1 Nm
