Image similar
Pepperl+Fuchs Sensor Inductive NBB5-F33-A0 084769 shielded NPN
EAN:
Part number:
Item no:
Product type
Sensor
Max. operating voltage
30 V DC
Contact type
Antivalent
Switching distance (max.)
5 mm
Outputs
NPN
Datasheet (PDF)
Technical specifications
- Product type
Sensor
- Type
NBB5-F33-A0
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Contact type
Antivalent
- Switching distance (max.)
5 mm
- Outputs
NPN
- Enclosure material
PBT
- Model
Inductive
- Installation type
shielded
- Connector
Cable
- Cable length
2 m
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP67
- Content
1 pc(s)
- Wireless charging
No
- Switching frequency
500 Hz
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2627905 Pepperl+Fuchs Sensor Inductive NBB5-F33-A0 084769 shielded NPN
User & Safety Instructions
User & Safety Instructions 2627905 Pepperl+Fuchs Sensor Inductive NBB5-F33-A0 084769 shielded NPN
Description
Switching distance: 5 mm, installation: Flush, switching function: Antivalent, output type: NPN, operating voltage: 10 ... 30 V DC, operating current: 0 ... 200 mA
This text is machine translated.
This text is machine translated.
Features
- General dataSwitching function: AntivalentOutput type: NPNSwitching distance: 5 mmInstallation: FlushOutput polarity: DCSafe switching distance: 0 ... 4.05 mmReduction factor forAl: 0.3Reduction factor rCu: 0.2Reduction factor rV2A (1.4301) : 0.6Output type: 4-wireCharacteristicsOperating voltage 10 ... 30 V DCSwitching frequency: 0 ... 500 HzHysteresis: type. 5%Reverse polarity protection: Reverse polarity protectedShort-circuit protection: IsochronousVoltage drop ≤ 3 VOperating current: 0 ... 200 mAResidual current: 0 ... 0.5 mA type. 0.1 µANo-load current ≤ 20 mAStandby delay: ≤ 10 msFunctional safety characteristicsMTTFd: 730 a.Service life (TM): 20 a.Diagnostic coverage level (DC): 0%Compliance with standards and directivesCompliance Standards EN 60947-5-2:2007 | IEC 60947-5-2:2007Approvals and certificatesUL approval: CULus Listed, General PurposeCSA approved: CCSAus Listed, General PurposeCCC approval: Products with a maximum operating voltage of ≤36 V are not subject to approval and therefore do not have a CCC marking.Ambient conditionsAmbient temperature: -25 ... 70 °C (-13 ... 158 °F)Mechanical data:Connection type: PVC cable, 2 mWire cross-section 0.34 mm2Housing material: PBTFace: PBTProtection class IP67
