Pepperl+Fuchs Sensor Inductive NCN3-F25-N4-V1 70133027 shielded NAMUR
EAN:
Part number:
Item no:
Product type
Sensor
Max. operating voltage
8.2 V
Switching distance (max.)
3 mm
Outputs
NAMUR
Model
Inductive
Datasheet (PDF)
Technical specifications
- Protection class: IP67
- UL approval: CULus Listed, General Purpose
- Safe switching distance: 0 ... 2.43 mm
- Output type: 2-wire
- Hysteresis: Type. 5%
- Reverse polarity protection: Reverse polarity protected
- Short-circuit protection: Yes
- Switching status indicator: LED, yellow
- Life (TM): 20a
- Product type
Sensor
- Type
NCN3-F25-N4-V1
- Max. operating voltage
8.2 V
- Operating voltage
8.2 V (max)
- Switching distance (max.)
3 mm
- Outputs
NAMUR
- Enclosure material
PBT
- Model
Inductive
- Installation type
shielded
- Connector
M12 x 1
M12 (4-pin)
- Features
LED indicator
- Min. temperature
-25 °C
- Max. temperature
+100 °C
IP67
- Content
1 pc(s)
- Switching frequency
1500 Hz
Documents & Downloads
Datasheet
Datasheet 2231837 Pepperl+Fuchs Sensor Inductive NCN3-F25-N4-V1 70133027 shielded NAMUR
User & Safety Instructions
User & Safety Instructions 2231837 Pepperl+Fuchs Sensor Inductive NCN3-F25-N4-V1 70133027 shielded NAMUR
