Image similar
Pepperl+Fuchs Sensor Inductive NRN75-FP-A2-P3 242779 non-shielded PNP
EAN:
Part number:
Item no:
Product type
Sensor
Max. operating voltage
30 V DC
Contact type
Antivalent
Switching distance (max.)
75 mm
Outputs
PNP
Datasheet (PDF)
Technical specifications
- Product type
Sensor
- Type
NRN75-FP-A2-P3
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Contact type
Antivalent
- Switching distance (max.)
75 mm
- Outputs
PNP
- Enclosure material
PBT
- Model
Inductive
- Material properties
painted
- Installation type
non-shielded
- Connector
Screw terminals
- Features
LED indicator
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP68
- Content
1 pc(s)
- Wireless charging
No
- Switching frequency
50 Hz
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2627683 Pepperl+Fuchs Sensor Inductive NRN75-FP-A2-P3 242779 non-shielded PNP
User & Safety Instructions
User & Safety Instructions 2627683 Pepperl+Fuchs Sensor Inductive NRN75-FP-A2-P3 242779 non-shielded PNP
Description
Switching distance: 75 mm, installation: Non-flush, switching function: Antivalent, output type: PNP, operating voltage: 10 ... 30 V DC, operating current: 0 ... 200 mA
This text is machine translated.
This text is machine translated.
Features
- General dataSwitching function: AntivalentOutput type: PNPSwitching distance: 75 mmInstallation: Non-flushOutput polarity: DCSafe switching distance: 0 ... 55 mmReduction factor forAl: 1Reduction factor rCu: 1Reduction factor rV2A (1.4301) : 1Reduction factor rSt37: 1Output type: 4-wireCharacteristicsOperating voltage 10 ... 30 V DCSwitching frequency: 0 ... 50 HzHysteresis: type. 3%Reverse polarity protection: Reverse polarity protectedShort-circuit protection: IsochronousVoltage drop ≤ 3 VTemperature drift: ± 10 % at 0 ... 50 °C (32 ... 122 °F) | ± 20 % at -25 ... 0 °C (-13 ... 32 °F) and 50 ... 70 °C (122 ... 158 °F)Rated insulation voltage 50 V.Operating current: 0 ... 200 mAResidual current: 0 ... 0.5 mANo-load current ≤ 20 mAStandby delay: ≤ 300 msOperating voltage display: LED, greenSwitching status indicator: LED, yellowFunctional safety characteristicsMTTFd: 824 a.Service life (TM): 20 a.Diagnostic coverage level (DC): 0%Compliance with standards and directivesCompliance Standards EN 60947-5-2:2007 | IEC 60947-5-2:2007Approvals and certificatesUL approval: CULus Listed, General PurposeCSA approved: CCSAus Listed, General PurposeCCC approval: Products with a maximum operating voltage of ≤36 V are not subject to approval and therefore do not have a CCC marking.Ambient conditionsAmbient temperature: -25 ... 70 °C (-13 ... 158 °F) | Mechanical data:Connection type: Screw terminalsConnection information: A maximum of 2 conductors with the same wire cross-section may be mounted at one clamping point! | Torque 1.2 Nm + 10 %Wire cross-section: Up to 2.5 mm2 Smallest wire cross-section: Without wire-end sleeves 0.5 mm2 , with wire-end sleeves 0.34 mm2 Largest wire cross-section: Without wire-end sleeves 2.5 mm2 , with wire-end sleeves 1.5 mm2Housing material: PBTFace: PBTHousing bottom: Aluminum, paintedProtection class: IP68
