Image similar
Pepperl+Fuchs Sensor Inductive NSN20-L2M-2E2-V1-S2D2 304275-000002 M12 non-shielded PNP
EAN:
Part number:
Item no:
Product type
Sensor
Max. operating voltage
30 V
Contact type
2 makers
Switching distance (max.)
20 mm
Outputs
PNP
Datasheet (PDF)
Technical specifications
- Product type
Sensor
- Type
NSN20-L2M-2E2-V1-S2D2
- Min. operating voltage
18 V
- Max. operating voltage
30 V
- Operating voltage
18 - 30 V
- Contact type
2 makers
- Switching distance (max.)
20 mm
- Outputs
PNP
- Enclosure material
Plastic (fibreglass reinforced)
- Model
Inductive
- Installation type
non-shielded
- Size
M12
- Connector
M12 plug (4-pin)
- Features
LED indicator
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP68
IP69
- Content
1 pc(s)
- Wireless charging
No
- Switching frequency
10 Hz
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2627839 Pepperl+Fuchs Sensor Inductive NSN20-L2M-2E2-V1-S2D2 304275-000002 M12 non-shielded PNP
User & Safety Instructions
User & Safety Instructions 2627839 Pepperl+Fuchs Sensor Inductive NSN20-L2M-2E2-V1-S2D2 304275-000002 M12 non-shielded PNP
