Pepperl+Fuchs Sensor Inductive SJ15-E-Y37062 037062 NPN (L x W x H) 30 x 48 x 60 mm Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Sensor
Max. operating voltage
30 V DC
Contact type
1 maker
Outputs
NPN
Datasheet (PDF)
Technical specifications
- Packaging type
Piece
- Product type
Sensor
- Type
SJ15-E-Y37062
- Min. operating voltage
10 V DC
- Max. operating voltage
30 V DC
- Operating voltage
10 - 30 V DC
- Contact type
1 maker
- Outputs
NPN
- Enclosure material
PBT
- Model
Inductive
- Connector
Cable
- Cable length
200 mm
- Min. temperature
-25 °C
- Max. temperature
70 °C
IP67
- Length
30 mm
- Width
48 mm
- Height
60 mm
- Dim
(L x W x H) 30 x 48 x 60 mm
- Content
1 pc(s)
- Wireless charging
No
- Switching frequency
500 Hz
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2627781 Pepperl+Fuchs Sensor Inductive SJ15-E-Y37062 037062 NPN (L x W x H) 30 x 48 x 60 mm Piece
User & Safety Instructions
User & Safety Instructions 2627781 Pepperl+Fuchs Sensor Inductive SJ15-E-Y37062 037062 NPN (L x W x H) 30 x 48 x 60 mm Piece
Description
Slot width 15 mm, switching function: Normally open contact (NO), output type: NPN, operating voltage: 10 ... 30 V DC, operating current: 0 ... 200 mA
This text is machine translated.
This text is machine translated.
Features
- General dataSwitching function: Closer (NO)Output type: NPNSlot width 15 mmImmersion depth (lateral): 17 ... 20 mmOutput polarity: DCOutput type: 3-wireCharacteristicsOperating voltage 10 ... 30 V DCSwitching frequency: 0 ... 500 HzReverse polarity protection: Reverse polarity protectedShort-circuit protection: IsochronousVoltage drop ≤ 3 VOperating current: 0 ... 200 mANo-load current ≤ 20 mACompliance with standards and directivesCompliance STANDARDS EN 60947-5-2:2007 | EN 60947-5-2/A1:2012 | IEC 60947-5-2:2007 | IEC 60947-5-2 AMD 1:2012Approvals and certificatesUL approval: CULus Listed, General PurposeCSA approved: CCSAus Listed, General PurposeCCC approval: Products with a maximum operating voltage of ≤36 V are not subject to approval and therefore do not have a CCC marking.Ambient conditionsAmbient temperature: -25 ... 70 °C (-13 ... 158 °F)Mechanical data:Connection type: Cable PVC, 200 mmWire cross-section 0.75 mm2Housing material: PBTProtection class IP67
