Pepperl+Fuchs Sensor Ultrasound Analogue UC250-F77-IU-IO-V31 Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Sensor
Max. operating voltage
30 V DC
Outputs
Analogue
Switching distance (max.)
250 mm
Datasheet (PDF)
Technical specifications
- Detection range 20 mm - 250 mm
- Blind zone: 0 mm - 20 mm
- Setting range 25 mm - 250 mm
- Standard plate 10 mm x 10 mm
- Converter frequency: Approx. 400 kHz
- Response delay: Minimum: 8 ms, factory setting: 29 ms
- Sensor cycle time: ≥ 8 ms (factory setting), parameterizable to 60 s.
- Non-volatile memory: EEPROM
- Write cycles: 300000
- LED green: Permanently on: Power on, flashing: Standby mode or IO-Link communication
- LED red: Permanently on: Fault, flashing: Programming of limits, object not detected
- No-load current ≤ 50 mA
- Storage temperature: -40 °C to +85 °C.
- Resolution: Current output: Evaluation range 3200 mm, however ≥ 0.35 mm, voltage output: Evaluation range 4000 mm, however ≥ 0.35 mm
- Interface type: IO-Link (available after activation via programming key until the next reset)
- Input/output type: 1 synchronization connection, bidirectional
- Input impedance> 22 kΩ
- Synchronization frequency, common mode: ≤ 141 Hz
- Reproducibility: ≤ ± 0.1% of the final value
- Converter: Epoxy resin/glass-shout ball mixture, foam polyurethane
- Weight 9 g
- Characteristic deviation: ≤ ± 1% from the end value
- Load impedance: Current output
- ≤ 500 Ohm, voltage output: ≥ 1000 Ohm
- Output current: Current source< 2.5 mA
- Standby delay: ≤ 300 ms
- All mounting positions permitted
- Power consumption ≤ 500 mW
- Packaging type
Piece
- Product type
Sensor
- Type
UC250-F77-IU-IO-V31
- Min. operating voltage
18 V DC
- Max. operating voltage
30 V DC
- Operating voltage
18 - 30 V DC
- Outputs
Analogue
- Switching distance (max.)
250 mm
- Model
Ultrasound
- Features
LED indicator
- Connector
M8 (4-pin)
- Enclosure material
Polycarbonate (PC)
- Contact type
Analogue
IP67
- Min. temperature
-25 °C
- Max. temperature
+70 °C
- UKCA
yes
