Pepperl+Fuchs Sensor Ultrasound M30 PNP NC UDCM-30GM-085-3E3
EAN:
Part number:
Item no:
Product type
Sensor
Max. operating voltage
30 V DC
Outputs
PNP NC
Switching distance (max.)
150 mm
Model
Ultrasound
Datasheet (PDF)
Technical specifications
- Converter frequency 85 kHz
- LED green: Display, single sheet detected
- LED red: Display: Double sheet detected
- Load current: 200 mA
- Storage temperature: -40 °C to +70 °C.
- Rated operating current: 3 x 100 mA, short-circuit/overload-proof
- Voltage drop ≤ 3 V
- Converter: Epoxy resin/glass-shout ball mixture, foam polyurethane
- Weight 300 g
- Impedance ≥ 4 kΩ
- Wire cross-section 0.14 mm²
- Product type
Sensor
- Type
UDCM-30GM-085-3E3
- Min. operating voltage
18 V DC
- Max. operating voltage
30 V DC
- Operating voltage
18 - 30 V DC
- Outputs
PNP NC
- Cable length
2.00 m
- Switching distance (max.)
150 mm
- Model
Ultrasound
- Connector
Cable
- Size
M30
- Material properties
nickel plated
- Enclosure material
Brass
PBT
- Contact type
3 breakers
IP65
- Min. temperature
0 °C
- Max. temperature
+50 °C
- Length
88 mm
- (Ø)
40 mm
- Dim
(Ø x L) 40 mm x 88 mm
- UKCA
not relevant
