PFERD TOOLS UGT HSSE DIN 335 C90° 12,4 25202182 Countersink 12.4 mm HSSE-Co 5 Cylinder shank 1 pc(s)
EAN:
Part number:
Item no:
Product type
Countersink
DIN standard
DIN 335-C
Ø
12.4 mm
Material
HSSE-Co 5
Material suitability
Steel (high alloyed)
Stainless steel
Datasheet (PDF)
Highlights & Details
Boring and countersunk tools UGT HSSE DIN 335 C90° 12.4
- Very quietLow lowering forces with good surface finishSpecially developed geometry with wide grooves for optimum chip and heat dissipationVery high removal rate and optimal chip removalBurr-free results even at low cutting speedsLong lifeHigh surface quality of the work piece
Technical specifications
- Product type
Countersink
- DIN standard
DIN 335-C
- Ø
12.4 mm
- Angle
90°
- Material
HSSE-Co 5
- Material properties
cobalt
- Material suitability
Steel (high alloyed)
Stainless steel
- Total length
56 mm
- Tool holder
Cylinder shank
- Shank Ø
8 mm
- Content
1 pc(s)
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 2626789 PFERD TOOLS UGT HSSE DIN 335 C90° 12,4 25202182 Countersink 12.4 mm HSSE-Co 5 Cylinder shank 1 pc(s)
User & Safety Instructions
User & Safety Instructions 2626789 PFERD TOOLS UGT HSSE DIN 335 C90° 12,4 25202182 Countersink 12.4 mm HSSE-Co 5 Cylinder shank 1 pc(s)
Description
PFERD countersinks are characterized by their especially sharp cutting edges, which achieve very good results even at low cutting speeds. High-performance tools with a countersink angle of 90° for lowering 90° screws for especially tough and hard materials such as alloyed and high-strength steel and stainless steel (INOX). The countersinks with inequality (UGT) are characterized by a specially developed geometry with wide gaps and thus enable optimum chip and heat removal, high smoothness and optimum work results. High durability and temperature-resistant execution by co-component.
This text is machine translated.
This text is machine translated.
