Phocos Solarladeregler Phocos ECO-N-20-T Charge controller PWM 12 V, 24 V 20 A
EAN:
Part number:
Item no:
Datasheet (PDF)
Highlights & Details
Solar charge regulator Phocos eco-N-20-T
- Ideal for almost any mains-independent PV-application
- The same model can be used in 12 or 24 V systems (fewer components in stock)
- Fully cast PCB
Technical specifications
- Product type
Charge controller
- Nominal voltage
12 V
24 V
- Charging current (max.)
20 A
- Own power consumption
4 mA
- Matching rechargeable battery
SLA
Lead-acid
- Control type
PWM
- Dim
(L x W x H) 61 x 100 x 20 mm
- Weight
160 g
- Width
100 mm
- Height
20 mm
- Length
61 mm
Documents & Downloads
Datasheet
Datasheet 3024608 Phocos Solarladeregler Phocos ECO-N-20-T Charge controller PWM 12 V, 24 V 20 A
User & Safety Instructions
User & Safety Instructions 3024608 Phocos Solarladeregler Phocos ECO-N-20-T Charge controller PWM 12 V, 24 V 20 A
Description
The ECO-N-T by Phocos is a cost effective solution for many demanding solar applications. Its compact size makes it possible to install it well even in small rooms.
The high-quality ECO-N-T is fully cast and protects the board against corrosion. This device also has UL and other certifications and is proof that it is a robust solar charging controller, which can be operated well in a variety of harsh environments.
The ECO-N-T is versatile and offers the flexibility to be operated with 12 or 24 volt systems. This reliable charge controller is easy to use as it does not require any user programming and has easy-to-read LEDs.
The ECO-N-T protects your batteries from over-charging and under-charging, thereby ensuring a high return on investment.
This text is machine translated.
The high-quality ECO-N-T is fully cast and protects the board against corrosion. This device also has UL and other certifications and is proof that it is a robust solar charging controller, which can be operated well in a variety of harsh environments.
The ECO-N-T is versatile and offers the flexibility to be operated with 12 or 24 volt systems. This reliable charge controller is easy to use as it does not require any user programming and has easy-to-read LEDs.
The ECO-N-T protects your batteries from over-charging and under-charging, thereby ensuring a high return on investment.
This text is machine translated.
Features
- Robust housing with corrosion-resistant screw terminals
- Three LEDs indicate the system status
- Installation requires only one flat-head screwdriver
- UL1741/Class I Div. 2 certified
Scope of delivery
- Solar charge regulator
- User manual.
