Buy Phoenix Contact 1415867 Sensor/actuator cable M8 Socket 5 m No. of pins (RJ): 3 1 pc(s)

Technical specifications

Design: Free cable end
Number of poles: 3
NOMINAL VOLTAGE 48 V AC;60 V DC
Flammability class to UL 94: HB
Mechanical Data: Mechanical Data
Ambient conditions: Environmental conditions
PROTECTION CLASS IP65;IP67;IP68
Ambient temperature (operation): -25 °C ... 80 °C (cable, fixed installation);-10 °C ... 80 °C (cable, moving laying)
Standards/regulations: IEC 61076-2-104
Insulation properties: Insulation properties
Overvoltage category II
Pollution level 3
Material contact surface Ni/Au
Nominal current IN: 4 A
Cable outside diameter 4.20 mm ±0.15 mm
Outer sheath, material: PVC
Material conductor: Plain Cu stranded conductor
Cable length 5 m
Cable cross-section: 3x 0.25 mm² (signal line)
M8 connector standard
Status display: No.
Outer sheath, color: Black RAL 9005
Application: Standard
Coding: A
Insulation resistance: ≥ 100 MΩ*km (at 20 °C)
Material contact: CuSn
Testing voltage ≤ 3000 V
Status display available: No.
Material contact carrier: TPU GF
Cable weight: 29 kg/km.
Shielded: No.
Cable type: Black PVC [PVC]
Conductor construction signal line: 14x 0.15 mm
AWG signal cable 24
Wire diameter including insulation: 1.17 mm ±0.05 mm
Material wire insulation: PVC
Single wire, color: Brown, blue, black
Wall thickness outer sheath: ≥ 0.76 mm
Complete stranding: 3 wires lengthways stranded
Nominal voltage cable ≥ 300 V
Minimum bend radius, 13 mm fixed installation
Non flammable: According to UL-Style 2464
Oil resistance EN 60811-2-1
Number of cable outlets: 1
Mating cycles ≥ 100
Track 1: Track 1
Coding type A
Track 2: Track 2
Wall thickness insulation: ≥ 0.23 mm (wire insulation)
Conductor resistance max.: 79 Ω/km (at 20 °C)
M8
Material of grip body: TPU, flame retardant, self extinguishing
Material: Die-cast zinc, nickel-plated
Ambient temperature (operation) (plug/socket): -25 °C ... 90 °C (plug/socket)
PVC black [PVC]: PVC black [PVC]
