Phoenix Contact 1458868 Sensor/actuator built-in connector M12 0.50 m No. of pins (RJ): 5 1 pc(s) Single
EAN:
Part number:
Item no:
Product type
Sensor/actuator built-in connector
No. of pins
5
Cable length
0.50 m
Nominal voltage
60 V
Nominal current
4 A
Technical specifications
- Packaging type
Single
- Type
SACC-E-M12MS-5CON-M16/0,5 VA
- Product type
Sensor/actuator built-in connector
- No. of pins
5
- Cable length
0.50 m
- Nominal voltage
60 V
- Nominal current
4 A
- Nominal current - rounded value
4 A
- Connection
Open end cable
- Thread type connection side
M12
- Thread type (wiring and installation)
M12
- Coding
A
- Contact material
CuZn
- Contact surface
Ni/Au
IP67
- Max. temperature
85 °C
- Manufacturer part #
1458868
- Content
1 pc(s)
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1828259 Phoenix Contact 1458868 Sensor/actuator built-in connector M12 0.50 m No. of pins (RJ): 5 1 pc(s) Single
Description
Pre-assembled with strands for immediate use. Customer-specific assemblies and wire lengths can be supplied. Wire-sided sealed for optimum leak tightness. All common pin allocation and codes for Signal, Data, and power transmission with uniform design-in-design. For high security of transmission: shield connection to the housing with optional EMC-nut.
