Phoenix Contact 1703050 Screw terminal 6.00 mm² Number of pins 1 Green 50 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
6.35 mm
Pins per row
1
Number of pins
1
Connection
Screw terminal
Print
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 1.93 / piece)
€ 96.63
plus VAT.
14-day return policy included
Highlights & Details
PCB terminal block FRONT 4-H-6,35
- Content 50 pc(s)
Technical specifications
- Type
FRONT 4-H-6,35
- Product type
Screw terminal
- Features
Stackable
- CS
6.35 mm
- No. of rows
1
- Pins per row
1
- Number of pins
1
- Series
FRONT
- Stripping length (max.)
14.00 mm
- Connection
Screw terminal
Print
- Nominal current
32 A
- Cross section (flexible) (min.)
0.50 mm²
- Nominal current - rounded value
32 A
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
6.00 mm²
- Cross section (inflexible) (max.)
6.00 mm²
- AWG (min.)
20
- Connector orientation
Parallel (to the PCB)
- AWG max.
10
- Contact material
Tin plated
- Enclosure material
Polyamide
- Factory colour
Green
- Actuation direction
Parallel (to the PCB)
- Manufacturer part #
1703050
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
320 V
- Width
31.00 mm
- Height
26.00 mm
- Length
6.35 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 192994 Phoenix Contact 1703050 Screw terminal 6.00 mm² Number of pins 1 Green 50 pc(s)
User & Safety Instructions
User & Safety Instructions 192994 Phoenix Contact 1703050 Screw terminal 6.00 mm² Number of pins 1 Green 50 pc(s)
Description
PCB terminal block, Nominal current: 32 A, Nom. voltage: 320 V, Pitch: 6.35 mm, Number of positions: 1, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °, Color: green, The article can be aligned to create different nos. of positions!
