Phoenix Contact 1707027 Screw terminal 1.50 mm² Number of pins 2 Green 50 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
7.62 mm
Pins per row
2
Number of pins
2
Connection
Screw terminal
Print
Datasheet (PDF)
Quantity (Set(s))
Savings
Package size (plus VAT.)
1
-
€ 31.92
3
4% = € 1.38
€ 30.54
Volume discounts vary depending on the seller
You save € 0.00
Total (€ 0.64 / piece)
€ 31.92
plus VAT.
Highlights & Details
PCB terminal block GMKDSN 1,5/ 2-7,62
- Content 50 pc(s)
Technical specifications
- Type
GMKDSN 1,5/ 2-7,62
- Product type
Screw terminal
- Features
+ extractor sleeve
- CS
7.62 mm
- Pins per row
2
- Number of pins
2
- Series
GMKDSN
- Stripping length (max.)
6.00 mm
- Connection
Screw terminal
Print
- Nominal current
16 A
- Cross section (flexible) (min.)
0.14 mm²
- Nominal current - rounded value
16 A
- Cross section (inflexible) (min.)
0.14 mm²
- Cross section (flexible) (max.)
1.50 mm²
- Cross section (inflexible) (max.)
1.50 mm²
- AWG (min.)
26
- Connector orientation
Parallel (to the PCB)
- AWG max.
16
- Contact material
Tin plated
- Factory colour
Green
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1707027
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
630 V
- Width
15.24 mm
- Height
13.50 mm
- Length
8.10 mm
Documents & Downloads
Datasheet
Datasheet 774530 Phoenix Contact 1707027 Screw terminal 1.50 mm² Number of pins 2 Green 50 pc(s)
Description
PCB terminal block, Nominal current: 16 A, Nom. voltage: 630 V, Pitch: 7.62 mm, Number of positions: 2, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °, Color: green, The article can be aligned to create different nos. of positions!
