Phoenix Contact 1736887 Screw terminal 4.00 mm² Number of pins 2 Black 50 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
6.35 mm
Pins per row
2
Number of pins
2
Connection
Screw terminal
Print
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 1.14 / piece)
€ 57.13
plus VAT.
Only 5 Set(s) available
Highlights & Details
PCB terminal block MKDS 5/ 2-6,35 BK Z1L TS
- Content 50 pc(s)
Technical specifications
- Type
MKDS 5/ 2-6,35 BK Z1L TS
- Product type
Screw terminal
- Features
+ extractor sleeve
Stackable
- CS
6.35 mm
- No. of rows
1
- Pins per row
2
- Number of pins
2
- Series
MKDS
- Min. stripping length
8 mm
- Stripping length (max.)
8 mm
- Connection
Screw terminal
Print
- Nominal current
32 A
- Cross section (flexible) (min.)
0.20 mm²
- Nominal current - rounded value
32 A
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
4.00 mm²
- Cross section (inflexible) (max.)
4.00 mm²
- AWG (min.)
24
- Connector orientation
Parallel (to the PCB)
- AWG max.
10
- Contact material
Cathode copper, tin plated
- Factory colour
Black
- Wire protection
Yes
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1736887
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
630 V
- Width
26.60 mm
- Height
12.70 mm
- Length
12.50 mm
Documents & Downloads
Datasheet
Datasheet 195367 Phoenix Contact 1736887 Screw terminal 4.00 mm² Number of pins 2 Black 50 pc(s)
User & Safety Instructions
User & Safety Instructions 195367 Phoenix Contact 1736887 Screw terminal 4.00 mm² Number of pins 2 Black 50 pc(s)
Description
PCB terminal block, Nominal current: 32 A, Nom. voltage: 630 V, Pitch: 6.35 mm, Number of positions: 2, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °
