Phoenix Contact 1777558 Screw terminal 4.00 mm² Number of pins 3 Green 50 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
6.35 mm
Pins per row
3
Number of pins
3
Connection
Screw terminal
Print
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 1.76 / piece)
€ 88.23
plus VAT.
14-day return policy included
Highlights & Details
PCB terminal block MKDS 5N HV/ 3-ZB-6,35
- Content 50 pc(s)
Technical specifications
- Type
MKDS 5N HV/ 3-ZB-6,35
- Product type
Screw terminal
- Features
+ extractor sleeve
- CS
6.35 mm
- Pins per row
3
- Number of pins
3
- Series
MKDS
- Stripping length (max.)
8.00 mm
- Connection
Screw terminal
Print
- Nominal current
41 A
- Cross section (flexible) (min.)
0.20 mm²
- Nominal current - rounded value
41 A
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
4.00 mm²
- Cross section (inflexible) (max.)
6.00 mm²
- AWG (min.)
24
- Connector orientation
Parallel (to the PCB)
- AWG max.
10
- Contact material
Tin plated
- Factory colour
Green
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1777558
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
1000 V
- Width
32.00 mm
- Height
19.05 mm
- Length
15.85 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 196642 Phoenix Contact 1777558 Screw terminal 4.00 mm² Number of pins 3 Green 50 pc(s)
User & Safety Instructions
User & Safety Instructions 196642 Phoenix Contact 1777558 Screw terminal 4.00 mm² Number of pins 3 Green 50 pc(s)
Description
PCB terminal block, Nominal current: 41 A, Nom. voltage: 1000 V, Pitch: 6.35 mm, Number of positions: 3, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °, Color: green
