Phoenix Contact 1822341 PCB terminal 1.5 mm² Number of pins 5 Black 220 pc(s)
EAN:
Part number:
Item no:
Product type
PCB terminal
CS
3.5 mm
Pins per row
5
Number of pins
5
Connection
Push-in spring-loaded terminal
Datasheet (PDF)
Technical specifications
- Type
SPT-THR 1,5/ 5-V-3,5 P26
- Product type
PCB terminal
- CS
3.5 mm
- No. of rows
1
- Pins per row
5
- Number of pins
5
- Series
SPT
- Connection
Push-in spring-loaded terminal
- Nominal current
17.5 A
- Cross section (flexible) (min.)
0.2 mm²
- Nominal current - rounded value
17.5 A
- Cross section (inflexible) (min.)
0.2 mm²
- Cross section (flexible) (max.)
1.5 mm²
- Cross section (inflexible) (max.)
1.5 mm²
- Connector orientation
Perpendicular (to the PCB)
- Contact material
Tin
- Factory colour
Black
- Manufacturer part #
1822341
- Content
220 pc(s)
- Height
16.2 mm
- UKCA
yes
