Phoenix Contact 1870420 Screw terminal 4.00 mm² Number of pins 3 Grey 50 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
7.62 mm
Pins per row
3
Number of pins
3
Connection
Screw terminal
Print
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 1.51 / piece)
€ 75.62
plus VAT.
14-day return policy included
Technical specifications
- Type
MKDS 5/ 3-7,62 GY
- Product type
Screw terminal
- Features
+ extractor sleeve
Stackable
- CS
7.62 mm
- No. of rows
1
- Pins per row
3
- Number of pins
3
- Series
MKDS
- Min. stripping length
8 mm
- Stripping length (max.)
8 mm
- Connection
Screw terminal
Print
- Nominal current
32 A
- Cross section (flexible) (min.)
0.20 mm²
- Nominal current - rounded value
32 A
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
4.00 mm²
- Cross section (inflexible) (max.)
4.00 mm²
- AWG (min.)
24
- Connector orientation
Parallel (to the PCB)
- AWG max.
10
- Contact material
Cathode copper, tin plated
- Factory colour
Grey
- Wire protection
Yes
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1870420
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
630 V
- Width
26.60 mm
- Height
22.86 mm
- Length
12.50 mm
Documents & Downloads
Datasheet
Datasheet 193600 Phoenix Contact 1870420 Screw terminal 4.00 mm² Number of pins 3 Grey 50 pc(s)
User & Safety Instructions
User & Safety Instructions 193600 Phoenix Contact 1870420 Screw terminal 4.00 mm² Number of pins 3 Grey 50 pc(s)
Description
PCB terminal block, Nominal current: 32 A, Nom. voltage: 630 V, Pitch: 7.62 mm, Number of positions: 3, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °
Hints
Special order, no right of withdrawal.
