Phoenix Contact 1877481 Screw terminal 1.50 mm² Number of pins 2 Green 50 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
5.08 mm
Pins per row
2
Number of pins
2
Connection
Screw terminal
Print
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 1.04 / piece)
€ 52.09
plus VAT.
Only 9 Set(s) available
Highlights & Details
PCB terminal block SMKDSNF 1,5/ 2-5,08
- SMKDSNF 1.5/2-5,08
- Industrial packaging, pack of 50
Technical specifications
- Type
SMKDSNF 1,5/ 2-5,08
- Product type
Screw terminal
- Features
+ extractor sleeve
- CS
5.08 mm
- Pins per row
2
- Number of pins
2
- Series
SMKDSNF
- Stripping length (max.)
8.00 mm
- Connection
Screw terminal
Print
- Nominal current
12 A
- Cross section (flexible) (min.)
0.14 mm²
- Nominal current - rounded value
12 A
- Cross section (inflexible) (min.)
0.14 mm²
- Cross section (flexible) (max.)
1.50 mm²
- Cross section (inflexible) (max.)
1.50 mm²
- AWG (min.)
26
- Connector orientation
At an angle (to the PCB)
- AWG max.
16
- Contact material
Tin plated
- Factory colour
Green
- Actuation direction
At an angle (to the PCB)
- Manufacturer part #
1877481
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
400 V
- Width
16.00 mm
- Height
15.50 mm
- Length
11.16 mm
Documents & Downloads
Datasheet
Datasheet 788046 Phoenix Contact 1877481 Screw terminal 1.50 mm² Number of pins 2 Green 50 pc(s)
User & Safety Instructions
User & Safety Instructions 788046 Phoenix Contact 1877481 Screw terminal 1.50 mm² Number of pins 2 Green 50 pc(s)
Description
PCB terminal block, Nominal current: 12 A, Nom. voltage: 400 V, Pitch: 5.08 mm, Number of positions: 2, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 325 °, Color: green
