Phoenix Contact 2702636 PSI-TERMINATOR-PB-TBUS PLC add-on module
EAN:
Part number:
Item no:
Technical specifications
- Type
PSI-TERMINATOR-PB-TBUS
- Product type
PLC add-on module
- Manufacturer part #
2702636
- Dim
(L x W x H) 73 x 22.5 x 92 mm
- Operating temperature
-40 °C (min)
- Min. operating temperature
-40 °C
- Width
22.5 mm
- Height
92 mm
- Length
73 mm
- Max. ambient temperature
+70 °C
- Min. ambient temperature
-40 °C
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1830277 Phoenix Contact 2702636 PSI-TERMINATOR-PB-TBUS PLC add-on module
Description
Fixed programming interface in the network. Scheduling from the outside can be activated. Mounting as a separate device or in the network. Extended temperature range -40°C ... +70°C. Galvanic separation of supply and data interface. Redundant power supply. Durchrangierung of the power using rail power for operation in the network.
