Phoenix Contact 2903208 FLKM 14-PA-MODI/M340 PLC adapter
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Ambient temperature (operation): -20 °C ... 60 °C
- Ambient temperature (storage/transport): -20 °C ... 60 °C
- Connection type: IDC/FLK pin strip
- Name Connection: Field level
- Conductor cross-section rigid: 0.2 mm² ... 2.5 mm²
- Conductor cross-section AWG: 24 ... 14
- Rated insulation voltage 63 V.
- Dimensioning surge voltage: 0.6 kV
- Schutzart1: ≥ IP54 (installation location)
- Max. Permissible operating voltage 25 V AC
- Number of ports: 2
- Number of pins: 14
- Tightening torque: 0.4 Nm
- Pollution level: 2
- Overvoltage category II
- Control: Schneider Electric Modicon M340
- Wire stripping length: 10 mm
- Conductor cross-section flexible: 0.2 mm² ... 2.5 mm²
- All mounting positions permitted
- Pitch: 2.54 mm
- Max. Permissible current: 1 A (per path)
- Product type
PLC adapter
- Type
FLKM 14-PA-MODI/M340
IP00
- Manufacturer part #
2903208
- Content
1 pc(s)
TRUE
FALSE
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2225483 Phoenix Contact 2903208 FLKM 14-PA-MODI/M340 PLC adapter
User & Safety Instructions
User & Safety Instructions 2225483 Phoenix Contact 2903208 FLKM 14-PA-MODI/M340 PLC adapter
Description
Varioface front adapter, for Schneider Electric Modicon M340
