Phoenix Contact 3002804 Distribution block 39.9 mm Pull spring Grey 20 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Distribution block
Connection
Pull spring
Cross section (flexible) (max.)
1.50 mm²
Cross section (inflexible) (max.)
1.50 mm²
Number (Package size 20 pc(s))
Total (€ 7.98 / piece)
€ 159.66
plus VAT.
14-day return policy included
Technical specifications
- Packaging type
Piece
- Product type
Distribution block
- Features
+ test option
- Connection
Pull spring
- Cross section (flexible) (min.)
0.14 mm²
- Cross section (flexible) (max.)
1.50 mm²
- Cross section (inflexible) (min.)
0.14 mm²
- Cross section (inflexible) (max.)
1.50 mm²
- Clamp width
39.9 mm
- No. of rows
1
- Pins per row
18
- Factory colour
Grey
- Nominal current
17.5 A
- Nominal current - rounded value
17.5 A
- Nominal voltage
500 V
- Manufacturer part #
3002804
- Content
20 pc(s)
- Type
PTFIX 18X1,5-G GY
- Dim
(L x W x H) 20 x 39.9 x 17.6 mm
- Width
39.9 mm
- Height
17.6 mm
- Length
20 mm
- Flammability rating
V0
- Connector colour
Grey
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1830818 Phoenix Contact 3002804 Distribution block 39.9 mm Pull spring Grey 20 pc(s) Piece
Description
Space-saving thanks to compact design. Flexible use through mounting rails and direct mounting. Space-saving potential distribution through compact micro-potential distribution. Ideal test options by testing openings at each terminal point. Clearly thanks to labelling of all terminal points.
