Phoenix Contact 3002864 Distribution block 14.7 mm Pull spring Blue 20 pc(s)
EAN:
Part number:
Item no:
Product type
Distribution block
Connection
Pull spring
Cross section (flexible) (max.)
1.50 mm²
Cross section (inflexible) (max.)
1.50 mm²
Nominal current - rounded value
17.5 A
Number (Package size 20 pc(s))
Total (€ 3.45 / piece)
€ 68.90
plus VAT.
Only 6 Set(s) available
Highlights & Details
Distributor block 3002864
- PTFIX 6X1,5-G BU
Technical specifications
- Product type
Distribution block
- Connection
Pull spring
- Cross section (flexible) (min.)
0.14 mm²
- Cross section (flexible) (max.)
1.50 mm²
- Cross section (inflexible) (min.)
0.14 mm²
- Cross section (inflexible) (max.)
1.50 mm²
- Clamp width
14.7 mm
- No. of rows
1
- Pins per row
6
- Factory colour
Blue
- Nominal current
17.5 A
- Nominal current - rounded value
17.5 A
- Nominal voltage
500 V
- Manufacturer part #
3002864
- Content
20 pc(s)
- Type
PTFIX 6X1,5-G BU
- Height
17.6 mm
- Length
20 mm
- Flammability rating
V0
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1830819 Phoenix Contact 3002864 Distribution block 14.7 mm Pull spring Blue 20 pc(s)
Description
Space-saving thanks to compact design. Flexible use through mounting rails and direct mounting. Space-saving potential distribution through compact micro-potential distribution. Ideal test options by testing openings at each terminal point. Clearly thanks to labelling of all terminal points.
