Phoenix Contact 3035686 Serial terminal 8.15 mm Push-in connector Grey 50 pc(s)
EAN:
Part number:
Item no:
Product type
Serial terminal
Connection
Push-in connector
Cross section (flexible) (max.)
6 mm²
Cross section (inflexible) (max.)
10 mm²
Content
50 pc(s)
Technical specifications
- Product type
Serial terminal
- Features
+ push-in spring bracket
- Connection
Push-in connector
- Cross section (flexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
6 mm²
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (inflexible) (max.)
10 mm²
- AWG (min.)
20
- AWG max.
8
- Clamp width
8.15 mm
- No. of rows
1
- Factory colour
Grey
- Stripping length (max.)
12 mm
- Manufacturer part #
3035686
- Content
50 pc(s)
- Type
PTME 6-DIO BY255/L-R
- Dim
(L x W x H) 100.8 x 8.2 x 100.8 mm
- Width
8.2 mm
- Height
100.8 mm
- Length
100.8 mm
- Flammability rating
V0
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1830874 Phoenix Contact 3035686 Serial terminal 8.15 mm Push-in connector Grey 50 pc(s)
