Phoenix Contact 3210442 Motor terminal Push-in connector Grey 50 pc(s) Piece
EAN:
Part number:
Item no:
Packaging type
Piece
Product type
Motor terminal
Connection
Push-in connector
Cross section (flexible) (max.)
4 mm²
Cross section (inflexible) (max.)
6 mm²
Highlights & Details
Motor connection terminal - PT 4-PE/3L - 3210442
- PT 4-PE/3L
Technical specifications
- Packaging type
Piece
- Product type
Motor terminal
- Connection
Push-in connector
- Cross section (flexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
4 mm²
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (inflexible) (max.)
6 mm²
- AWG (min.)
24
- AWG max.
10
- No. of rows
4
- Number of pins
7
- Factory colour
Grey
- Min. stripping length
10 mm
- Stripping length (max.)
12 mm
- Manufacturer part #
3210442
- Content
50 pc(s)
- Type
PT 4-PE/3L
- Dim
(L x W x H) 104.40 x 6.2 x 104.4 mm
- Width
6.2 mm
- Height
104.4 mm
- Length
104.40 mm
- Flammability rating
V0
- Connector colour
Grey
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1831078 Phoenix Contact 3210442 Motor terminal Push-in connector Grey 50 pc(s) Piece
