Phoenix Contact 3270118 Shunt distributor 8.3 mm Pull spring Blue 10 pc(s)
EAN:
Part number:
Item no:
Product type
Shunt distributor
Connection
Pull spring
Cross section (flexible) (max.)
1.50 mm²
Cross section (inflexible) (max.)
1.50 mm²
Nominal current - rounded value
10 A
Number (Package size 10 pc(s))
Total (€ 7.73 / piece)
€ 77.30
plus VAT.
14-day return policy included
Highlights & Details
The marshalling rack 3270118
- PTRV 4 BU/BU
Technical specifications
- Product type
Shunt distributor
- Connection
Pull spring
- Cross section (flexible) (min.)
0.14 mm²
- Cross section (flexible) (max.)
1.50 mm²
- Cross section (inflexible) (min.)
0.14 mm²
- Cross section (inflexible) (max.)
1.50 mm²
- Clamp width
8.3 mm
- No. of rows
4
- Pins per row
4
- Factory colour
Blue
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Nominal voltage
250 V
- Manufacturer part #
3270118
- Content
10 pc(s)
- Type
PTRV 4 BU/BU
- Height
55.5 mm
- Length
64 mm
- Flammability rating
V0
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1831484 Phoenix Contact 3270118 Shunt distributor 8.3 mm Pull spring Blue 10 pc(s)
Description
Blue version for use for intrinsically safe circuits in hazardous areas (protection type Ex i). High contact quality by push-in Technology as a replacement for wire wrap, termi-point, etc. individual color assignment of conductor and clamping point to error-free, safe working. Tool-free wiring in a confined space by compact size.
