Phoenix Contact Pin housing PCB MDSTB Total number of pins 4 Contact spacing: 5.08 mm 1762062 50 pc(s)
EAN:
Part number:
Item no:
Product type
Pin housing PCB
Connector type
Plug, horizontal mount
No. of rows
2
Series
MDSTB
CS
5.08 mm
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 1.45 / piece)
€ 72.26
plus VAT.
14-day return policy included
Highlights & Details
Base strip MDSTB 2,5/ 2-G-5,08
- Content: 50 pc(s)
- No. of rows: 2
- Total number of pins: 4
Technical specifications
- Product type
Pin housing PCB
- Connector type
Plug, horizontal mount
- No. of rows
2
- Connector system
wire-to-board
- Series
MDSTB
- Features
2-tier
encodable
- CS
5.08 mm
- Pins per row
2
- Total number of pins
4
- Width
26.90 mm
- Nominal current
10 A
- Nominal current - rounded value
10 A
- Content
50 pc(s)
- Dim
(L x W x H) 12.70 x 26.90 x 22.10 mm
- Connection
Print
- Manufacturer part #
1762062
- Factory colour
Green
- Industrial packaging
Yes
- Contact material
Tin plated
- Nominal voltage
320 V
- Height
22.10 mm
- Length
12.70 mm
- Connector orientation
Parallel (to the PCB)
- Type
MDSTB 2,5/ 2-G-5,08
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 567067 Phoenix Contact Pin housing PCB MDSTB Total number of pins 4 Contact spacing: 5.08 mm 1762062 50 pc(s)
User & Safety Instructions
User & Safety Instructions 567067 Phoenix Contact Pin housing PCB MDSTB Total number of pins 4 Contact spacing: 5.08 mm 1762062 50 pc(s)
Description
Header, Nominal current: 10 A, Rated voltage (III/2): 320 V, Number of positions: 2, Pitch: 5.08 mm, Color: green, Contact surface: Tin, Assembly: Soldering, Can be aligned! Mounting flange: Order no. 1736771, 1736768. In combination with MVSTB or FKCV plugs, both an MVSTBW (or FKCVW) and an MVSTBR plug (or FKCVR) must be used. Combination with TMSTBP plugs is not possible!
