Phoenix Contact Pin housing cable FKIC Total number of pins 2 Contact spacing: 5.08 mm 1945821 100 pc(s)
EAN:
Part number:
Item no:
Product type
Pin housing cable
Connector type
Plug, straight
No. of rows
1
Series
FKIC
CS
5.08 mm
Datasheet (PDF)
Number (Package size 100 pc(s))
Total (€ 1.18 / piece)
€ 117.64
plus VAT.
14-day return policy included
Highlights & Details
Printed-circuit board connector FKIC 2,5 HC/ 2-ST-5,08 BD:5X3
- Content: 100 pc(s)
- No. of rows: 1
- Total number of pins: 2
Technical specifications
- Product type
Pin housing cable
- Connector type
Plug, straight
- No. of rows
1
- Connector system
wire-to-board
- Series
FKIC
- Features
+ push-in spring bracket
- CS
5.08 mm
- Pins per row
2
- Total number of pins
2
- Width
27.00 mm
- Nominal current
16 A
- Nominal current - rounded value
16 A
- Content
100 pc(s)
- AWG max.
12
- AWG (min.)
24
- Dim
(L x W x H) 12.16 x 27.00 x 15.00 mm
- Connection
Spring-loaded terminal
Plug
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1945821
- Factory colour
Green
- Industrial packaging
Yes
- Contact material
Tin plated
- Connector contact surface
Tin plated
- Nominal voltage
320 V
- Height
15.00 mm
- Length
12.16 mm
- max. cross section
2.5 mm²
- Min. cross section
0.2 mm²
- Type
FKIC 2,5 HC/ 2-ST-5,08 BD:5X3
Documents & Downloads
Datasheet
Datasheet 193261 Phoenix Contact Pin housing cable FKIC Total number of pins 2 Contact spacing: 5.08 mm 1945821 100 pc(s)
User & Safety Instructions
User & Safety Instructions 193261 Phoenix Contact Pin housing cable FKIC Total number of pins 2 Contact spacing: 5.08 mm 1945821 100 pc(s)
Description
Plug component, Nominal current: 16 A, Number of positions: 2, Pitch: 5.08 mm, Connection method: Spring-cage conn., Color: green, Contact surface: Tin
