Phoenix Contact QUINT4-BUFFER/24DC/40 2908283 UPS buffer
EAN:
Part number:
Item no:
Datasheet (PDF)
Technical specifications
- Protection class: IP20
- Ambient temperature (operation): -25 °C ... 70 °C (> 40 °C derating: 0.56 %/K /> 60 °C derating: 2.5 %/K)
- Max. Permissible Humidity (Operating): ≤ 95%
- Climate class: 3K3 (according to EN 60721)
- Pollution level: 2
- Installation height ≤ 4000 m.
- Product type
UPS buffer
- Input voltage (max.)
30 V DC
- Min. input voltage
22.5 V DC
- Output voltage (max.)
24 V DC
- Output voltage (min.)
24 V DC
- Dim
(W x H x D) 72 x 130 x 125 mm
- Output current (details)
40 A
- Weight
1.2 kg
- Width
72 mm
- Height
130 mm
- Depth
125 mm
- Type
QUINT4-BUFFER/24DC/40
- Features
Capacitive energy storage
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 2137310 Phoenix Contact QUINT4-BUFFER/24DC/40 2908283 UPS buffer
User & Safety Instructions
User & Safety Instructions 2137310 Phoenix Contact QUINT4-BUFFER/24DC/40 2908283 UPS buffer
Description
Space saving through compact design. Maintenance-free due to electrolytic capacitors. Through soft start-up can also be used with power supplies in the low power range.
